6.2 ZigBee Sample Programs
In order to run the sample programs discussed in this chapter and elsewhere in this manual,
1. Your module must be plugged into the Prototyping Board as described in Chapter 2,
“Getting Started.”
2. Dynamic C must be installed and running on your PC.
3. The programming cable must connect the programming header on the RCM4510W to
your PC.
4. Power must be applied to the module through the Prototyping Board.
5. The Digi ? XBee USB used as the ZigBee coordinator must be connected to an avail-
able USB port on your PC if you are exercising the ZigBee protocol, or you need a
second RCM4510W module if so instructed.
Refer to Chapter 2, “Getting Started,” if you need further information on these steps.
To run a sample program, open it with the File menu (if it is not still open), then compile
and run it by pressing F9 .
Each sample program has comments that describe the purpose and function of the pro-
gram. Follow the instructions at the beginning of the sample program.
The sample programs in the Dynamic C SAMPLES\RCM4500W\XBee and SAMPLES\XBee
folders illustrate the use of the XBee function calls.
6.2.1 Setting Up the Digi XBee USB Coordinator
1. Connect the Digi ? XBee USB acting as a ZigBee coordinator to an available USB port
on your PC or workstation. Your PC should recognize the new USB hardware.
2. Compile and run the XBEE_GPIO_SERVER.C sample program in the Dynamic C
SAMPLES\RCM4500W\XBee folder.
3. Open the ZigBee Utility by double-clicking XBEE_GPIO_GUI.exe in the Dynamic C
Utilities\XBee GPIO GUI folder — if you have problems launching the ZigBee
Utility, install a .Net Framework by double-clicking dotnetfx.exe in the Dynamic C
Utilities\dotnetfx folder. You may add a shortcut to the ZigBee Utility on your
desktop.
4. Confirm the following hardware setup is displayed on the “PC Settings” tab.
? 115200 baud
? Hardware flow control
? 8 data bits
? No parity
? 1 stop bit
User ’s Manual
59
